Nowicki High-Speed Rotation Vacuum Bowl Cutters with Cooking Option
The Nowicki High-Speed Rotation Vacuum Bowl Cutters with Cooking Option are advanced processing machines designed for the efficient production of emulsified and cooked meat products. By integrating cutting, mixing, vacuum, and cooking functionalities, these cutters enhance product quality, flavor, and processing efficiency.
Description
Equipped with a dual heating system—comprising bowl jacket heating and steam injection into the knife chamber—these cutters allow simultaneous thermal treatment and emulsification. This integration reduces processing time and improves the consistency and flavor of the final product.
Key Features
Dual Heating System: Combines bowl jacket heating with steam injection for efficient cooking.
Vacuum Processing: Enables up to 90% vacuum for improved product texture and shelf life.
High-Speed Operation: Adjustable cutterhead speeds up to 4,800 rpm for precise emulsification.
Versatility: Suitable for a wide range of products, including sausages, pâtés, and plant-based alternatives.
User-Friendly Interface: Touchscreen control panel with programmable settings for consistent results.
Hygienic Design: Constructed with stainless steel and designed for easy cleaning and maintenance.
Technical data
|
Model |
Bowl Capacity (dm³) |
Cutterhead Speed (rpm) |
Mixing Speed (rpm) |
Length (mm) |
Width (mm) |
Height with Lowered Cover (mm) |
Height with Raised Cover (mm) |
Weight (kg) |
|---|---|---|---|---|---|---|---|---|
|
KN-200V |
200 |
100–4,800 |
-100 to -300 |
3,075 |
2,900 |
2,060 |
2,690 |
5,490 |
|
KN-330V |
330 |
100–4,500 |
-100 to -300 |
3,250 |
3,160 |
2,180 |
2,750 |
7,140 |
|
KN-550V |
550 |
200–3,800 |
-100 to -300 |
3,975 |
3,510 |
2,400 |
3,200 |
9,500 |
|
KN-750V |
750 |
100–3,500 |
-100 to -300 |
3,980 |
3,960 |
2,650 |
3,450 |
14,0 |
